產品名稱：走蒸汽的電動截止閥j941h-16c dn350生產廠家[ 2023-08-07 ]

: 訂購熱線：021-64162222

: 訂購傳真：021-62677999

: 質量穩定：實行全過程質量監控，細致入微全方位檢測！

: 價格合理：高效內部成本控制，減少了開支，讓利于客戶

: 交貨快捷：先進生產流水線，充足的備貨，縮短了交貨期！

產品介紹
規格尺寸
結構圖片

一、走蒸汽的電動截止閥j941h-16c dn350生產廠家介紹
上海湖泉閥門集團有限J941H-16C DN350電動鑄鋼法蘭截止閥的啟閉件是塞形的閥瓣,密封面呈平面或錐面,閥瓣沿流體的中心線作直線運動。閥桿的運動形式,有升降桿式(閥桿升降,手輪不升降),也有升降旋轉桿式(手...公稱通徑 350mm 密封材料合金鋼閥門性能特點旋塞式工作介質 氣體、水、油品公稱壓力 1.6Mpa 連接方式法蘭執行器性能特點適用于公稱壓力pn1．6～16mpa，工作溫度0～425℃的石油、化工、制藥、化肥、電力行業等各種工況的管路上，切斷或接通管路介質。驅動方式有手動、齒輪傳動、電動、氣動等。鑄鋼法蘭截止閥的啟閉件是圓柱形的閥瓣，密封面呈平面或錐面，閥瓣沿流體的中心線作直線運動。國標截止閥只適用于全開和全關，一般不用來調節流量，定做時允許作調節和節流。

二、走蒸汽的電動截止閥j941h-16c dn350生產廠家型號

J941H-16CP DN300/J941H-16CP DN350/J941H-16CP DN400/J41H-25CP DN40/J41H-25CP DN50/J941H-25CP DN65/J41H-25CP DN80/J41H-25CP DN100/J41H-25CP DN125/J41H-25CP DN150/J941H-25CP DN200/J41H-25CP DN250/ J41H-25CP DN300/J41H-25CP DN350/J41H-25CP DN400/J41H-10CP DN40/J41H-10CP DN50/J41H-10CP DN65/J41H-10CP DN80/J41H-10CP DN100/J41H-10CP DN125/J41H-10CP DN150/J941H-10CP DN200/J41H-10CP DN250/ J41H-10CP DN300/J41H-10CP DN350/J41H-10CP DN400/J41H-16CP DN40/J41H-16CP DN50/J41H-16CP DN65/J41H-16CP DN80/J41H-16CP DN100/J41H-16CP DN125/ J41H-16CP DN150/J41H-16CP DN200/J41H-16CP DN250/J41H-16CP DN300/ J41H-16CP DN350/J41H-16CP DN400/J41H-25CP DN40/J41H-25CP DN50/J41H-25CP DN65/J41H-25CP DN80/J41H-25CP DN100/J41H-25CP

型號	J41Y-16C J41Y-16R J941Y-16C J941W-16R
公稱通徑DN	PN 1 . 6 Mpa								WT ( KG )
公稱通徑DN	L	D	D1	D2		Z-Φd	H	D0	J41	J941
15	130	95	65	45	14	4 -Φ14	218	120	4.8	5.2
20	150	105	75	55	14	4 -Φ14	258	140	6.5	7.1
25	160	115	85	65	14	4 -Φ14	275	160	7.0	7.4
32	180	135	100	78	16	4 -Φ18	280	180	8.2	8.5
40	200	145	110	85	16	4 -Φ18	330	200	11.0	12.5
50	230	160	125	100	16	4 -Φ18	350	240	14.5	20
65	290	180	145	120	18	4 -Φ18	400	280	21.5	25
80	310	195	160	135	20	8-Φ18	355	280	27	35
100	350	215	180	155	22	8-Φ18	415	320	30	50
125	400	245	210	185	24	8-Φ18	460	360	84	75
150	480	280	240	210	26	8-Φ23	510	400	91	100
200	600	335	295	265	26	12-Φ23	710	400	148	210
250	730	405	355	320	30	12-Φ25	786	450	405	446
300	850	460	410	375	30	12-Φ25	925	500	610	648
